Duff Tuff Ash Gray Hoodie
|
|
Hi Ho Silver Trosely Cartoon Shirt, Tan, Adult
|
Our Price: $25.00
Sale Price: $19.95
You save $5.05!
|
|
|
Our Price: $15.00
Sale Price: $9.95
You save $5.05!
|
|
|
|
|
|
Ash Gray Heavyweight 9.5oz 80/20 Cotton/Poly Hoodie in Adult sizes S-XXL with the Duff Tuff Brand on the front and DUFFTUFF.com down the left sleeve.
|
Hi Ho Silver, Ben & Suzy on the trail in a cartoon done by George Trosley on the back. James Duff oval logo on the left front chest of a 100% cotton Tan shirt in adult sizes M-XXL.
|
|
|
|
Stainless Inner Fender Stone Guards, 1966-77 Bronco
|
|
Duffy's Dark Gray Hoodie
|
Our Price: $89.95
Sale Price: $79.95
You save $10.00!
|
|
|
|
Our Price: $25.00
|
|
|
|
|
|
Have a beautiful paint job you want to protect it? These 18 gauge stainless steel guards keep rocks from flying up into your inner fenders and giving it an outie (paint ding from the outside). Also. gives a nice finished look to your wheel wells. Attach with screws.
|
Heavy Weight 9.5oz 50/50 Cotton/Poly Hoodie in Adult sizes, S-XXL with Old School Softball Style Duffy's Logo on front and DUFFTUFF.com down the left sleeve.
|
|
|
|
Nugent/Stacey David Fullsize Bronco Solid Axle Swap Info
|
|
Upper Quarter Panel Storage Trays, 1966-77 Bronco
|
|
|
Our Price: $75.00
Sale Price: $63.95
You save $11.05!
|
|
|
|
|
The Ted Nugent Project Phoenix Bronco featured on Stacey David's Gearz TV was a challenge in that it came with a lot of previous work done to it along with the shear bulk of the Currie Rock Jock Dana 60 Axles. The truck is running 42" Iroks which Stacey decided on after seeing them on our Hi Ho Loco. The truck also has a 4" body lift which allowed us to do a few things differently than we would on production version of the parts. Since then we have also done a Dana 44 Swap under Bronco Driver Magazine's Project Full Force. This project was a little more like what most people are doing and we revised a few of the parts to reflect this. We aren't selling this in a kit form because there are too many variables as to what people want or need due to different lift heights. Here is what parts we used on the front end of Full Force:
Full Force had a BDS 4" TTB Lift Kit utilizing add-a-leafs in the rear. The Bronco was sitting a little rear high when we started. We ended up with approximately 5 1/8"lift on the front (these coil towers sit lower than factory buckets). Right now it is sitting a little nose high but it doesn't have a winch on the winch bumper.
Early Bronco 5.5" Coils #5109 $170
HD Coil Buckets #5110 $125 For spring steel frames require drilling countersunk holes for mounting. We used 1/2" x 1 1/2" Flat Socket Caps, 1/2" flat washers and Nyloc Nuts. The placement and number of bolts will vary depending on bucket placement and lift height and if the end user is going to stretch the wheelbase.
Lower Retainers #5120 $75 If using EB coil springs, no modification necessary. If using a larger wire diameter coil (like 78-79 springs), it will require either stripping a little of the coating or opening up the retainer loop a touch.
Stage 3 Long Travel Tubular Arms #5351 $749
New Bolt on Dual Shock mounts #5225 $100
12" Travel Shocks #8114 $36x4=$144 Taller lifts could use our 15" travel #8120 which run $45 each
SAS Track Bar Bracket 1980-96 FSB $99.95 Designed to bolt into the stock bolts and engine crossmember. Requires drilling holes in front engine cross member and it will need to be trimmed in order to clear track bar on up travel.
Adjustable Track Bar #5408 $149.95
Heim Joint Steering System #5645 $389.95 Built to measurements as lengths will vary depending on axle used.
C-bushings Depends on lift height (we used 4° on this lift) $29
Rear End of Ted Nugent Project Phoenix:
#5111 EB Coil Spring Towers, Tall, pair $125
#5120 HD Lower Coil Retainer Cups, pr $75
#8120 15" Long Travel Duff 70/30 Shocks, $45 each x4
#5360 4-Link Kit Upper & Lower Links
Custom Frame Mounts for Upper and Lower Links
Prototype Coil Springs approximately 5-51/2" lift
Early Bronco 4link Shock Mount Crossmember made taller & wider to fit FSB
Custom Truss & Lower Shock Mounts to work on the Currie Rock Jock Axle
We do not have plans to make a production 4 link kit for the 78 and up Broncos or F150's. There are far too many variables to make this a simple bolt/weld on kit. This includes frame reinforcement, ride height and shock mounts with a full body intact.
|
Storage space in an EB is at a premium. These 16 Gauge Steel trays make use of the wasted space under the upper quarters above the rear wheel houses. Perfect space for trail parts and tools. We had these powder coated red and run them in Hi Ho Loco where the narrowed body really makes space a premium!
|
|
|
